Engine Manufacturer / Brand:
CAT
Engine Model:
3412
Product Description:
Arrangement number: 177-8882
HP range: (1200,1250,1300,1350,1400 BHP) AT 2300 RPM
When plugged into the ECM, it states 1400HP
When plugged into the ECM, it states 1400HP
Fully disassembled to the bare block and re- machined and assembled
including Line hone, Deck surface, reman heads with new valve guides and keepers, Reman rods with new bushings, Crankshaft checked for straightness, hardness and polished std std
New injectors
New piston Piston packs with Cat pistons
Reman Turbochargers
Reman Injectors
New Water pumps
Reman Camshafts and new lifters
New oil cooler
New Thermostats
New oil pump
New fuel and oil filters
Cleaned and pressure tested after coolers.
Cleaned and tested/re sealed Heat exchangers
Gear train fully inspected and re-bushed
New Rod and Main bearings
Everything is thoroughly cleaned in and out and re-sealed with all new gaskets.
Additional Information:
The engines originally were 4k hour engines. They didn’t need rebuilt other than the fact they took on water in the crank cases and rusted some of the internal components. All the sensors and ECM’s got re used. They Did not take on water though. The engines were build for a larger corporation who doesn’t want them anymore, they want to go to a 3512.
