Gear Manufacturer / Brand:
Twin Disc
Gear Model:
MG5075A
Ratio:
2.05:1
Product Description:
Twin Disc MG5075A Marine Gear – Ratio 2.05:1
Pleasure Craft (@ 2500 RPM): 455 kW (610 hp)
Light Duty (@ 2300 RPM): 368 kW (493 hp)
Intermediate Duty (@ 2100 RPM): 283 kW (380 hp)
Medium Duty (@ 1800 RPM): 205 kW (275 hp)
Continuous Duty (@ 1800 RPM): 186 kW (249 hp)
General Specifications
Design: Near coaxial, lightweight aluminum housing with a 7° down angle
Maximum Input Speed: 3500 RPM max allowable (varies by duty cycle/rating limits)
Standard Equipment: Mechanical control valve and oil strainer
Available Housing Options: SAE J617 housing No. 1, No. 2, or No. 3
Flywheel Compatibility: SAE J620 size 355 (14″) or size 290 (11.5″) flexible couplings
CFR178 12V
