Condition:
Used
Product Description:
165′ x 43′ x 12′ Former ABS Deck barge with heavy deck and 4′ bin wall. Built in 2008 and ready to work.
Hull Structure:
Deck: 5/8″ plate
Sides 3/8″ plate
Bottom: 3/8″ plate
Bulkheads 3/8″ plate
Deck Transverse frames: 12″ x 25# Channel
Bottom Transverse frames: 10″ x 20# Channel
Side Transverse: 7″ x 14# Channel
Transverse Frames Spaced at 6′ 7 1/2″ between BHD’s
Deck Long’ls: 5″ x 3 1/2″ x 5/16″ every 24″
Side Long’ls: 4″ x 3″ x 5/16″ every 36″
Bottom Long’ls: 5″ x 3 1/2″ x 5/16″ every 24″
Bhd Stiffiners: 5″ x 3 1/2″ x 5/16″ every 24″
Deck Fittng:
6 – 36″ Kevels
4 – 13″ Dbl. Bits
16 – 18″ Flush Centerbolt Manhole
Bin Wall:
Material of wall: 1/2″
Height: 48″
Length: 138′
Width: 36′
